Model No.: TigerVH
Brand: FAW
| Category | Specification |
| Model Name | FAW Jiefang Tiger VH |
| Vehicle Class | Light–Medium Duty Truck |
| Drive Type | 4×2 |
| Typical Use | Urban and regional logistics, express delivery, cold-chain, general freight |
| Engine Options | Weichai WP3.2NQ / WP4.1NQ |
| Power Output | 130–170 HP |
| Torque | Up to 500 Nm |
| Transmission | FAST 6-speed manual / Optional AMT |
| Fuel Tank Capacity | 100L / 120L / 160L (steel or aluminum) |
| Emission Standard | China VI B |
| Wheelbase Options | 3300 mm / 3800 mm / 4200 mm |
| GVW (Gross Vehicle Weight) | 6–9 tons |
| Chassis Layout | Ladder frame, multi-leaf suspension, adaptable to flatbed, box, refrigerated |
Cabin & Comfort
| Cab Type | Wide-body, flat-floor, mid-roof sleeper |
| Interior Trim | Fabric or easy-clean vinyl, ergonomic design |
| Dashboard | LCD cluster (hybrid digital-analog), multifunction steering wheel |
| Driver’s Seat | Mechanical or optional air suspension seat |
| Air Conditioning | Manual A/C standard, electronic A/C optional |
| Infotainment | Optional 7” touchscreen, USB ports, Bluetooth, radio, reversing camera support |
| Cabin Comfort | High NVH insulation, 12V charging port, sun visors |
| Standard Safety | ABS + EBD, dual-circuit air brakes |
| Optional Safety | ESC, LDWS, TPMS, reversing radar/camera |
| Smart Connectivity | Optional FAW Zhitu Telematics: GPS, fuel analysis, fleet diagnostics |
| Brake System | Air brake system with exhaust brake (retarder optional on select trims) |
| Fuel Consumption | Approx. 11–14L / 100 km depending on load and road conditions |
| Maintenance Access | Modular engine bay, common spare parts, national service coverage |
| Efficiency Highlights | High torque at low RPM, matched axle ratios for optimized fuel use |
| Industry | Example Usage |
| E-commerce logistics | Urban parcel delivery, B2B express distribution |
| Cold-chain distribution | Fresh produce, pharmaceuticals, dairy, cold beverages (with reefer box) |
| Retail/chain supply | Store replenishment, beverage delivery, small-batch FMCG |
| Construction supplies | Light construction goods, tools, paint, and building materials |
| Agriculture / wholesale | Fruits, vegetables, farm-to-market transport |
Product Categories : Chassis Truck > TigerVH Chassis Truck
